01. PD Meter FPD-02

Summary:

The PD Meter is a digital precision optical instrument used to measure distance
between human pupils in the process of optometry for fitting spectacles.

Detailed Product Description:

1, It employs precise optical structure, the line of light is very clear and
precise measurement.The measurement results are displayed digitally,and
the left eye and right eye measuring values are displayed separately.

2, Simple and rapid measuring operation, and free operation of the direct
PD adjustment lever are possible.Combining with the adjustable viewing
distance selecting lever for measuring all kind of the viewing distances,
the PD measurement is simple and precise.

3, When the measuring operation is finished, the auto poweroff and memory
function,enable to save the power and not to lose the data.

4, It can also be used in monocular the left eye and right eye separately.

Parameter:

Effective range of measurement:

binocular pupillary distance:45-80mm,
left or right pupillary distance:22.5-40mm.

Indication error: ≤0.5mm

Distan    ce of target: 30cm ~ infinate

Electric Voltage: DC 4.5V(3pcs 5# AA battery)

Power: 10W

Weight:  0.6kg

Volume: 21.5(L)x15(w)x50(H)cm

FPD-2-1 FPD-2-2FPD-2-3
